DIH775A-B is a polyimide film-backed tape with two sides coated
silicone adhesive, which has excellent properties of high
temperature resistance.
Features And Benefits:
1. Excellent tensile strength & Elongation
2. Withstand Long periods of heat up to 260℃ ; withstand short time
of heat up to 300℃
3. Both-sides with different adhesion, no any residue after
removal.
High Temperature Double Sided Tape Properties:
| Item | | Typical Value |
| Imperial | Metric |
| Backing | 3.0mils | 0.075mm |
| Total Thickness | 8.0±0.4mil | 0.200±0.01mm |
| Adhesion to Steel | 1.8lbs/in | A adhesive:8.0N/25mm |
| 0.18lbs/in | B adhesive: 0.8N/25mm |
| Tensile Strength | ≥45.7lbs/in | ≥8(KN/M) |
| Elongation | ≥50% | ≥50% |
| Breakdown voltage | >8KV | >8KV |
Operating Temperature | 536℉ | 280℃ |
Construction:
Application:
1. Mask for printed circuit boards during wave solder or solder dip
process.
2. Masking contacts during spray painting, powder coating & solder
coating.
3. Bundling of transformer, motor, battery & electronic components
for insulation purpose.
Storage:
1. Store under normal conditions of 10-30℃ and 40-70% R.H, out of
direct sunlight.
2. Shelf life: 12 months from the date of manufacture when stored
in initial packing.
Precaution Reminder:
1. Surface should be clean, dry, free of dust, oil or other
contaminants.
2. Proper pressure required by roller, hand or press when applying.
3. Avoid repeat sticking to prevent adhesion decrease.
Why buy from us instead of buying from other suppliers?
1. Good location and convenient transportation.
2. SGS certification.
3. Advanced production and processing equipment, environmentally
friendly and reliable products.
Notes:
Please be advised that this technical data sheet is written based
on our lab tests and experience only. Customer is responsible to
determine the suitability of the product meets intended application
requirements before approved for use.
